PITFT50 V2.0 DSI Display for Raspberry Pi

BIGTREETECHSKU: BTT-PITFT-50-v2.0
No reviews

Price:
Sale price£43.00

Description

Introducing the BIGTREETECH PI TFT 50 V2.0 - a 5 inch LCD touchscreen display designed for Raspberry Pi. With an 800x480 resolution, adjustable brightness, and Klipper Screen compatibility, it's the perfect addition to your project.

Features

  • The BTT PI TFT 50 V2.0 is a 5-inch LCD touchscreen display designed for Raspberry Pi, with a resolution of 800x480 and a display area of 108x64.8mm.
  • Compatible with the Raspberry Pi DSI display interface and features a capacitive touch panel that supports 5-point touch. It can be directly driven by DSI.
  • Unique hole design on the back for direct installation of Raspberry Pi, and uses the Raspberry Pi power supply design, eliminating the need for an external power supply.
  • Easily adjust the backlight brightness of the PI TFT50 display using the hardware adjustment feature. Simply rotate the potentiometer located behind the screen to achieve your desired brightness level.

Specifications

  • Working Voltage: 3.3V (provided by Raspberry Pi display interface)
  • Maximum Working Current: 320mA
  • Screen Current: 100mA
  • Screen Resolution: 800*480
  • Video Interface: Raspberry Pi DSI
  • Touch Points: 5 points
  • Viewing Angle: 60°/70°/70°/70°
  • RGB888-16 Trillion True Color
  • Refresh Rate: 60Hz
  • Luminous Rate: 280 cd/m2
  • Working Temperature: -20℃-70℃
  • Dimensions: 121mm x 76mm
  • Mounting Hole Size: M2.5
  • Outer Mounting Hole Position: 113mm x 68mm
  • Inner Mounting Hole Position: 58mm x 49m
